CI-4 Diesel Engine Oil
CI-4 diesel engine oil with four SAE grades in the performance table. Compare the selected grade's hot viscosity and low-temperature limits before ordering.
Choose your specification.
Select a grade or type, pack size and quantity. We will use these details to prepare your quotation.
Packaging image not available for this option. The product can still be included in your inquiry.
RunChee · CI-4 Diesel Engine Oil · 5W-30 · 4 L
Select grade & packaging.
Series: Engine Oil Series
5W-30 · 4 L
Your selection is carried into the inquiry form. Carton quantity refers to the number of individual containers in one carton.
Available grades & packaging
| Grade / designation | Packaging options | Choose |
|---|---|---|
| 5W-30 | 4 L · 6 containers/carton; 18 L · individual container | |
| 10W-30 | 4 L · 6 containers/carton; 18 L · individual container | |
| 15W-40 | 4 L · 6 containers/carton; 18 L · individual container | |
| 20W-50 | 4 L · 6 containers/carton; 18 L · individual container |
Where to use this product.
Applications
Diesel trucks, generators and equipment whose manuals require CI-4 oil. Supply the engine requirement with the selected grade.
- 01
The viscosity ranges distinguish the SAE 30, 40 and 50 operating-temperature grades.
- 02
Flash point and pour point limits vary by SAE grade.
- 03
The table also covers evaporation loss, water, impurities, cold cranking and pumping viscosity.
Compare the grades before ordering.
Check the test conditions and limits alongside the grade you are ordering.
| Property / test condition | 5W-30 | 10W-30 | 15W-40 | 20W-50 | Test method |
|---|---|---|---|---|---|
| Kinematic viscosity (100°C), mm²/s | 9.3~<12.5 | 9.3~<12.5 | 12.5~<16.3 | 16.3~<21.9 | GB/T265 |
| Flash point (Open cup), °C (min.) | 200 | 205 | 215 | 215 | GB/T3536 |
| Pour point, °C (max.) | -35 | -30 | -25 | -20 | GB/T3535 |
| Mechanical impurities, %** (max.) | 0.01 | 0.01 | 0.01 | 0.01 | GB/T511 |
| Water, % (max.) | Trace | Trace | Trace | Trace | GB/T260 |
| Evaporation loss (250°C, 1h), % (max.) | 15 | 15 | 15 | 15 | SH/T0059 |
| Low-temperature dynamic viscosity, mPa・s * (max.) | 6600(-30°C) | 7000(-25°C) | 7000(-20°C) | 9500(-15°C) | GB/T6538 |
| Low-temperature pumping viscosity, mPa・s * At no yield stress (max.) | 60000(-35°C) | 60000(-30°C) | 60000(-25°C) | 60000(-20°C) | SH/T0562 |
| Foaming characteristics (Tendency / Stability), ml/ml · GB/T12579 | |||||
| 24°C (max.) | 10/0 | 10/0 | 10/0 | 10/0 | GB/T12579 |
| 93.5°C (max.) | 20/0 | 20/0 | 20/0 | 20/0 | GB/T12579 |
| After 24°C (max.) | 10/0 | 10/0 | 10/0 | 10/0 | GB/T12579 |
Swipe or scroll inside the table to compare columns. Limits are reproduced from the supplied product specification. “Report” indicates a result to be reported; “—” indicates no value stated. Request the current TDS for the exact grade.
Product documents for your selected grade.
The performance comparison above is available online. Request a current TDS or SDS for this model and grade; document availability and revision are confirmed with your request.
Before you request a quotation.
Which grade or type should I select?
The listed grades or types are 5W-30, 10W-30, 15W-40, 20W-50. Match the selection to your equipment manual or formulation requirement. If you are unsure, send us the equipment model and the specification you are working to.
What packaging can I request?
Listed packaging: 4 L · 6 containers/carton; 18 L · individual container. Confirm availability, order quantity and shipping details in the written quotation.
Does the picture cover every specification?
Packaging photos are references for the grade and pack shown in the caption. A listed specification can still be requested when there is no matching photo.
Can I request the TDS, SDS or approval information?
Ask for the current TDS for the exact grade and the relevant SDS. Tell us the destination country and any approval requirement so document availability can be confirmed before the order.
What information do you need for a quotation?
Include CI-4 Diesel Engine Oil, the grade or type, pack size, quantity and delivery destination. Add your equipment requirement or document request where relevant. We will confirm the product and supply details in a written quotation.
Request CI-4 Diesel Engine Oil.
Send the grade or type, pack size, quantity and delivery destination. We will confirm the product and supply details in a written quotation.
